3D Scanner

3D Scanner

+ Free Shipping
分类：
3D scanner
model SimScan series KScan
SimScan 30 SimScan 30 Gen 2 SimScan E KSCAN Magic KSCAN Magic II KSCAN E KSCAN E
Recommended 0.1 to 2m 0.1 to 2m 0.1 to 2m 0.1 to 4 m 0.1 to 4m 0.05 to 8m 0.5 to 15m
Part Size
Accuracy 0.02 mm 0.02 mm 0.02 mm 0.02 mm 0.02 mm 0.02 mm 0.02 mm
Volumetric 0.015 mm + 0.035 mm/m 0.015 mm + 0.035 mm/m 0.015 mm + 0.035 mm/m 0.015 mm + 0.030 0.015 mm + 0.030 0.015 mm + 0.030 0.075 mm + 0.010
Accuracy mm/m mm/m mm/m mm/m
Light source 22 blue laser crosses 34 blue laser crosses 63 blue laser crosses 22 blue laser crosses 34 blue laser crosses 108 blue laser crosses 84 blue laser crosses
7 blue laser parallel 17 blue laser parallel 17 blue laser parallel 7 blue laser parallel 7 blue laser parallel 17 blue laser parallel 54 blue laser parallel
1 blue laser single 1 blue laser single 1 blue laser single 1 blue laser single 1 blue laser single 1 blue laser single 1 blue laser single
11 IR parallel 11 IR parallel 38 IR crosses
Scan area 650 mm × 550 mm 700 mm × 600 mm 700 mm × 600 mm 1440 mm × 860 mm 1440 mm × 860 mm 1440 mm × 1000 mm 2600 mm × 1800 mm
Measurement speed 2,020,000 / sec 4,580,000 / sec 6,300,000 / sec 2,700,000 / sec 4,150,000 / sec 8,290,000 / sec 6,40,000 / sec
Photogrammetry No No No Yes Yes Yes Yes
Wirelss No No Yes No No Yes Yes
